Product Description:
Tactile Push Button Switch 12x12x7.3mm – Red Square Head (3.8mm), Through-Hole Type
This 12mm x 12mm tactile push-button switch is a compact, reliable momentary switch designed for general-purpose PCB applications. It features a square red actuator cap (3.8mm height), making it suitable for devices requiring easy and tactile feedback.
With through-hole mounting and a standard 7.3mm overall height, it ensures secure placement on PCBs. It’s ideal for control panels, consumer electronics, industrial instruments, and DIY electronics.
📦 Package Includes:
-
1 x 12x12x7.3mm Red Tactile Push Button Switch (Square Head, Through Hole)
🔧 Specifications:
-
Switch Type: Momentary Tactile Push Button
-
Body Size: 12mm x 12mm
-
Actuator Type: Square Head
-
Actuator Color: Red
-
Actuator Height: 3.8mm
-
Mounting Type: Through Hole
-
Overall Height: 7.3mm
-
Contact Rating: 12V DC, 50mA
-
Contact Resistance: ≤ 50 mΩ
-
Operating Temperature: -30°C to +80°C
-
Terminal Quantity: 4 Pins
-
Durability: Long operational life
📐 PCB Layout & Dimensions:
-
Mounting Hole Distance: 9.0mm x 9.0mm
-
Pin Spacing: 5.0mm (horizontally), 9.0mm (vertically)
-
PCB Hole Diameter: 1.2mm for pins, 1.7mm for mount tabs
✨ Features:
-
Excellent tactile feedback with audible click
-
Durable plastic housing and metal contact structure
-
Easy to solder and reliable for repeated operations
-
Suitable for manual or automated PCB assembly
⚙️ Applications:
-
Arduino and embedded systems
-
Consumer electronics
-
Remote controls
-
Industrial control panels
-
DIY electronics projects
