STM8S005K6T6CTR 8-bit Microcontroller – 32KB Flash, 16MHz – LQFP-32

The STM8S005K6T6CTR is a high-performance 8-bit microcontroller from the STMicroelectronics STM8S Value Line, designed for cost-sensitive industrial, appliance, and general embedded applications. With a 16MHz STM8 core, 32KB Flash, 2KB SRAM, and 128 bytes of true EEPROM, this MCU delivers a powerful and flexible architecture suitable for real-time control and multi-interface embedded designs.

Featuring 25 programmable I/O pins, a fast 10-bit ADC with 7 channels, and multiple communication interfaces including I²C, SPI, and UART/USART, the STM8S005K6T6CTR provides wide connectivity for sensor interfacing, motor control, and automation tasks. Its reliability is enhanced through features such as independent watchdogs, brown-out reset, and clock security system, ensuring stable operation under demanding environments.

Housed in a compact LQFP-32 package, the MCU offers an efficient footprint while providing rich functionality ideal for compact device designs.

Key Specifications:

• Core Architecture: STM8 8-bit core

• CPU Frequency: Up to 16MHz

• Flash Memory: 32KB

• SRAM: 2KB

• EEPROM: 128 bytes (true data EEPROM)

• Operating Voltage: 2.95V to 5.5V

• GPIO: 25 programmable I/O pins

• ADC: 10-bit, 7 channels

• Interfaces: I²C, SPI, UART/USART

• Package: LQFP-32 (7×7 mm)

• Operating Temperature: –40°C to +85°C

Applications:
Industrial controllers, sensors, home appliances, IoT modules, automation systems, motor control, and general embedded solutions.

Package Includes:
1 x STM8S005K6T6CTR Microcontroller IC

Note: Image is for representation purpose only.
