MT3608L Step-Up Converter IC | 1.2MHz Boost Regulator 2.5A – SOT23-6

The MT3608L is a high-efficiency 1.2MHz step-up (boost) DC-DC converter IC designed for compact, low-power applications. With its integrated 80mΩ power MOSFET, adjustable over-current protection, and wide 2.2V to 16V input range, this IC delivers exceptional performance for battery-powered devices and portable electronics.

Capable of producing output voltages up to 20V with efficiency levels reaching 93%, the MT3608L operates in constant-frequency current-mode control, enabling the use of small, low-profile inductors and capacitors. Its automatic PFM mode improves efficiency at light loads, extending battery life.

Typical protections include undervoltage lockout, thermal shutdown, current limiting, and over-voltage protection, ensuring reliable operation even under demanding conditions. The compact SOT23-6 package makes it ideal for space-constrained power supply designs.

Features / Specifications

• Model: MT3608L

• Package: SOT23-6

• Input Voltage: 2.2V to 16V

• Output Voltage: Adjustable, up to 20V

• Efficiency: Up to 93%

• Switching Frequency: 1.2MHz

• Integrated Power MOSFET: 80mΩ

• Adjustable Over-Current Protection: 0.5A to 2.5A

• Max Switch Current: 2.5A (OC pin floating)

• Internal Compensation & Soft Start

• Automatic PFM at light load

• Over-Voltage Protection

• Applications:

  • Portable devices

  • LED drivers

  • Battery-powered equipment

  • IoT & embedded systems

  • DC-DC boost power modules

Package Includes:
1 × MT3608L Step-Up Converter IC – SOT23-6

Note: Product images are for representation purposes only and may differ from the actual product.
