TL494CD PWM Controller IC – Texas Instruments – SOIC-16 Package

TL494CD PWM Controller IC – Texas Instruments – SOIC-16 Package

The TL494CD from Texas Instruments is a versatile PWM (Pulse Width Modulation) controller IC designed for switching power supplies and motor control applications. It operates with a wide supply voltage range of 7V to 40V and can handle switching frequencies up to 300 kHz, making it suitable for high-efficiency power management designs.

🔹 Key Features:

• Manufacturer: Texas Instruments

• Package: SOIC-16 (SOP-16)

• Operating Voltage: 7V to 40V supply range

• Switching Frequency: Up to 300 kHz

• Number of Outputs: 2

• Output Current: Up to 200 mA

• Operating Temperature Range: 0°C to +70°C

• External switch transistor required (no built-in switch)

• No synchronous rectifier function

📦 Package Includes:

• 1 × TL494CD PWM Controller IC (SOIC-16 Package)

🖼️ Note:

Product images are for reference only and may differ from the actual product.

📄 Related Documents:

Please refer to the TL494 datasheet attached for detailed technical specifications and application guidelines.
