16 Pin USB Type C Female SMD Connector SMT PCB Mount Receptacle

Circuitcomps

16 Pin USB Type C Female SMD Connector SMT PCB Mount Receptacle

Name: 16 Pin USB Type C Female SMD Connector SMT PCB Mount Receptacle
Brand: Circuitcomps
SKU: CC-001139
Price: 6.3 INR
Availability: InStock

Product SKU: CC-001139

Available:

Only 50 items in stock

50 items in stock

In stock

Pre-order

Out of stock

₹6.30

~~₹7.35~~

For B2B orders, contact us on sales@circuitcomps.com

Manufacturer Part No.

CC-001139
Device Type

USB Connector (PCB Mount)
Connector Type

USB Type-C Female
Number of Pins

16
Mounting Style

Surface Mount (SMD/SMT)
Current Rating

3 A (maximum)
Rated Voltage

30 V (maximum)
Contact Resistance

40 mΩ (maximum)
Insulation Resistance

100 MΩ (initial)
Operating Temperature

−40°C to +85°C
Plug Orientation

Reversible (USB Type-C)
Approximate Weight

0.95 g
Mounting Type

Surface Mount (SMD/SMT)
Operating Function

PCB-mount USB Type-C receptacle for power and data communication
Applications

USB Type-C charging ports, development boards, embedded systems, IoT devices, mobile accessories, consumer electronics, DIY electronics, PCB repair, portable devices
Suitable For

Compact PCB layouts, USB-powered devices, prototyping and production-grade designs
Features

Reversible plug orientation, low contact resistance, high insulation resistance, wide operating temperature range, compact SMT footprint
Function

Provides reliable USB Type-C female interface for PCB-mounted charging and data transfer applications
Electrical Characteristics

3A max, 30V max, 40mΩ contact resistance, 100MΩ insulation resistance

Description
Specifications
Reviews

The 16 Pin USB Type C Female SMD Connector is a high-quality surface-mount receptacle designed for compact electronic devices requiring reliable USB Type-C connectivity. Its reversible connector design eliminates plug orientation concerns, making it convenient and user-friendly for charging and data transfer applications.

Designed with a 16-pin SMT footprint, this connector supports up to 3A current and 30V operating voltage, making it suitable for USB-powered devices, development boards, IoT products, consumer electronics, and embedded systems. The space-saving surface-mount design enables compact PCB layouts while ensuring reliable electrical performance and mechanical stability.

Key Specifications

Connector Type: USB Type-C Female
Number of Pins: 16
Mounting Style: Surface Mount (SMD/SMT)
Current Rating: 3 A (maximum)
Rated Voltage: 30 V (maximum)
Contact Resistance: 40 mΩ (maximum)
Insulation Resistance: 100 MΩ (initial)
Operating Temperature: −40°C to +85°C
Plug Orientation: Reversible (USB Type-C)
Approximate Weight: 0.95 g

Package Includes

1 x 16 Pin USB Type C Female SMD Connector SMT PCB Mount Receptacle

Note: Image is for representation purpose only.
