IR2110 High and Low Side Driver IC – SMD-16 Package

⚡ IR2110 High and Low Side Driver IC – SMD-16 Package

The IR2110 is a high-speed, high-voltage power MOSFET and IGBT driver IC, ideal for driving half-bridge and full-bridge power circuits. With independent high-side and low-side drivers, it supports output voltages up to 500V and works seamlessly with both 3.3V and 5V logic levels.

Its undervoltage lockout (UVLO) protection and bootstrap operation make it highly suitable for motor drives, inverters, switch-mode power supplies (SMPS), and other power control applications. The compact SMD-16 package offers space efficiency for PCB designs.

🔧 Features:

• Floating Channel: Bootstrap-capable high-side operation up to 500V

• Gate Drive Supply Voltage: 10V to 20V

• 3.3V Logic Compatible: Works with modern low-voltage microcontrollers

• Undervoltage Lockout (UVLO): Ensures safe operation on both channels

• Separate Logic Supply: 3.3V to 20V logic interface flexibility

• Fast Switching Capability: Suitable for high-frequency applications

📦 Package Includes:

1 × IR2110 High and Low Side Driver IC – SMD-16 Package
