M24C64-RMN6TP 64Kbit I2C Serial EEPROM - STMicroelectronics

The M24C64-RMN6TP by STMicroelectronics is a high-performance 64-Kbit (8 Kbyte) serial I2C EEPROM designed for high reliability and long-term data storage. Featuring built-in Error Correction Code (ECC) and an exceptional 200-year data retention rating, it is ideal for configuration storage, data logging, and device identification in industrial and consumer electronics applications.

Key Specifications

• Manufacturer: STMicroelectronics
• Memory Size: 64 Kbit (8 Kbyte)
• Interface: I2C (100 kHz, 400 kHz, 1 MHz)
• Supply Voltage: 1.8V to 5.5V
• Package: SOIC-8 (Surface Mount)
• Operating Temperature: -40°C to +85°C
• Endurance: 4,000,000 Write Cycles
• Data Retention: 200 Years
• Page Write: 32-byte page write, 5 ms write cycle time
• Key Features: Built-in ECC, Hardware Write Protection, Power-On Reset (POR), Low Power

Package Includes

• 1 x M24C64-RMN6TP 64Kbit I2C Serial EEPROM - STMicroelectronics

Note: Image is for representation purpose only.
