MH-SR602 Mini PIR Motion Sensor Module – 3.3V–15V 120° 3–5m Detection

Circuitcomps

MH-SR602 Mini PIR Motion Sensor Module – 3.3V–15V 120° 3–5m Detection

Name: MH-SR602 Mini PIR Motion Sensor Module – 3.3V–15V 120° 3–5m Detection
Brand: Circuitcomps
SKU: CC-001255
Price: 83.74 INR
Availability: InStock

Product SKU: CC-001255

Available:

Only 1 item in stock

1 item in stock

In stock

Pre-order

Out of stock

₹83.74

~~₹89.25~~

For B2B orders, contact us on sales@circuitcomps.com

Manufacturer Part No.

MH-SR602
SKU

CC-001255
Device Type

Passive Infrared (PIR) Mini Motion Sensor Module
Sensing Distance

3 m – 5 m
Detection Angle

120°
Operating Voltage

3.3 V – 15 V DC
Output Signal

Digital High (3.3V) / Low (0V)
Quiescent Current

20 µA
Default Output Delay

2.5 seconds
Adjustable Delay Range

2.5s – ~1 hour (SMD resistor swap)
Delay Resistor Guide

0Ω = 2.5s | 10kΩ = ~25s | 100kΩ = ~250s | 1MΩ = ~41 min
Lockout / Blocking Time

2 seconds (fixed)
Housing

Black plastic Fresnel lens structure
Dimensions

15 mm x 15 mm x 20 mm
Weight

20 g
Mounting Type

PCB module (through-hole header pins)
Operating Function

Human motion detection via passive infrared sensing
Applications

Home Security, Smart Lighting, Battery-Powered IoT Wake Triggers, Interactive Displays, Kiosks
Suitable For

Arduino / ESP32 Developers, IoT Engineers, Security System Integrators, Makers, Students
Features

Ultra-Compact 15x15mm Footprint, 20µA Quiescent Current, 3.3V Digital Output, Adjustable Delay via SMD Resistor, 2s Anti-False-Trigger Lockout, Wide 3.3–15V Supply Range
Function

Ultra-compact PIR motion sensor module for battery-powered and microcontroller-based human presence detection with digital output and adjustable delay
Electrical Characteristics

3.3–15V DC input, 20µA quiescent current, 3.3V digital high output, 2s lockout, 2.5s–1hr adjustable delay

Description
Specifications
Reviews

The MH-SR602 Mini Motion Sensor Detector Module is an ultra-compact, high-sensitivity pyroelectric infrared (PIR) proximity sensor engineered for real-time human movement detection. Operating across a wide supply voltage range of 3.3V to 15V DC while drawing just 20µA quiescent current, this micro-sized module is an ideal hardware baseline for battery-powered smart automation, security alarms, and micro-power Arduino projects.

Key Specifications

Product Model: MH-SR602 / SR602
Sensor Type: Passive Infrared (PIR) Mini Motion Sensor
Sensing Distance: 3 m to 5 m
Detection Angle: 120° conical coverage
Operating Voltage: 3.3 V to 15 V DC
Output Signal: Digital — High (3.3V) / Low (0V)
Quiescent Current: 20 µA (ultra-low static power draw)
Default Output Delay: 2.5 seconds
Adjustable Delay Range: 2.5 seconds to ~1 hour (via SMD resistor swap)
Lockout / Blocking Time: 2 seconds (fixed)
Housing Color: Black plastic Fresnel lens structure
Dimensions: 15 mm × 15 mm × 20 mm
Weight: 20 g

Package Includes

1 x MH-SR602 Mini PIR Motion Sensor Module

Note: Image is for representation purpose only.
